Standing Type Electric Pallet Stacker Polyurethane Wheel With Long Working Time

Name: Standing Type Electric Pallet Stacker Polyurethane Wheel With Long Working Time
Brand: REACH
Price: 1 USD

Brand Name : REACH

Model Number : QDAC

Certification : CE

Place of Origin : Zhejiang, China

MOQ : 1 set

Price : negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 200 sets per month

Delivery Time : 25 - 30 days

Packaging Details : 1set / pallet

Capacity : 1200/1500kg

Max. lifting height : 2500/3000/3500mm

Min. fork height : 85mm

Free lift : 380mm

Fork size : 60/170/1150mm

Forks width : 570/685mm

Drive motor power : 0.75kw

Battery : 24V120/210/240AH

Contact Now

1200kg standing type electric pallet stacker with long working time for 10 hours

Quick Details:

Description: Electric Pallet Stacker QDAC
Capacity: 1200/1500kg
Max. lifting height: 2500mm, 3000mm, 3500mm
Fork dimensions: 60/170/1150mm

Free lift: 380mm
Drive motor: 0.75kw

Battery: 24V120/210/240AH

Advantages:

Fully free lifting 380mm.
Minimum height of mast is 2000mm.
The cylinder is big, the current is small, the power consumption is low, so that the working time of this electric pallet stacker can reach 10 hours.
The four pivot structure is optimized and the chassis is stable and safe.
High quality H type steel mast, the stiffness increased 30% than that of carbon steel.
Built in high energy sealed battery, long-term maintenance free, no need to adding liquid or water.
Stepless control speed, to meet the rhythm of different drivers.
The whole vehicle components and pipeline layout is reasonable, convenient maintenance, no similar electric pallet stacker maintenance trouble.
Beautiful in appearance and graceful in curve.

SPECIFICATIONS
Model		QDAC
Driving type		Electric
Operating		Standing
Rated capacity	kg	1200/1500
Load center distance	mm	500
Wheels		polyurethane wheel
Steering wheel	mm	210*70
Fork wheel single	mm	115*50
Fork wheel tandem	mm	80*70
Max. lifting height	mm	2500/3000/3500
Free lift height	mm	380
Lowered mast height	mm	1740/1990/2240
Overall height	mm	3050/3550/4050
Min. fork height	mm	85
Overall length	mm	2050
Forks size	mm	60/170/1150
Forks width	mm	570/685
Ground clearance	mm	50
Max. Gradient, load/unload	%	3/5
Travel brake		Electromagnetic braking
Driving motor power	kw	0.75
Lifting motor power	kw	2
Battery	V/Ah	24/120/210(240)
Steering		Mechanical steering

Standing Type Electric Pallet Stacker Polyurethane Wheel With Long Working Time
